'Perhaps the bigger news for enthusiasts is that Ford pairs the power to an old-school six-speed manual transmission. The gearbox is a a drag-strip proven CALIMER TRANSMISSIONS - Stage 3 version of the Getrag MT82 6-speed transmission with billet internals, beefed up to withstand 1,000 pound-feet (1,356 Newton-meters) of instant torque. Automatic Transmission 3.8L ID: F8ZP-AA Fits 1998 Ford Mustang 586956 (Fits: Ford Mustang) $250.00 MT82 D4 REMAN DOUBLE OVERDRIVE 6 SPD 23 SPLINE FOR 2018 FORD MUSTANG. MT82 Transmission Specs, Problems, and Fixes. The Getrag MT82 transmission found in 2011-2020 manual Ford Mustangs doesn’t have the best reputation. It's known for causing a number of shifting issues and even transmission failure in some cases. But there are some upgrades that can help fix the problems with the MT82 and MT82-D4 transmissions.

Mt82 transmission lawsuitTransmission

MT82 Getrag 6-Speed Manual Transmission Workshop Manual PDF

Mt82 Transmission

Manual Transmission The MT82 6-speed transmission features:

  • six forward speeds and one reverse speed.
  • helical toothed gear wheels and gears that arc constantly engaged.
  • triple synchronisation on 1st and 2nd gears.
  • double synchronisation on 3rd and 4th gears.
  • a shift interlock system to prevent the engagement of more than one gear.
  • a skip shift system to bypass 2nd and 3rd gears for vehicles equipped with 5.0L (4V) engines.
  • aluminum front and rear main cases.
  • an input shaft, output shaft and countershaft.
  • ball bearings on input shaft, output shaft and countershaft.
  • a reverse idler gear to produce a reverse rotation of the output shaft.

The transmission function is to move the vehicle from a rest position to motion. This is done by transferring the engine torque to the vehicle rear wheels. The transmission uses gears to adapt the torque to the demands of load and road conditions. It matches engine power to vehicle needs.

This power is delivered from the engine flywheel, to the transmission. The power is transmitted through a driver-operated clutch, which allows for engagement and disengagement of the engine to the transmission.

The transmission input shaft receives the power when the clutch is engaged. It is transferred through the input shaft to the drive gear. Torque is transferred to the countershaft drive gear and is delivered along the countershaft to all the countershaft gears. Torque is then transferred to the engaged mainshaft gear. The transmission then uses a system of mainshaft gears to change the speed and torque relationship between the engine crankshaft and the transmission output shaft.

Language: English
Format: PDF
Pages: 72

Automatic[edit]

  • 1950–1965 Ford-O-Matic
  • 1958–1979 Cruise-O-Matic
    • 1968–1981 FMX—A hybrid of the FX and MX
    • 1964–1981 C4
      • Most small-block V8 powered cars of the 1960s and 1970s in the North American market
    • 1966–1996 C6
      • Most big-block V8 powered cars/trucks of the 1960s and 1970s in the North American market, All Fseries trucks without O/D, 80 thru 96 (97 For F250HD, F350, and F-Superduty models)
    • 1974–1989 C3—Light-duty, smaller than the C4
    • 1982–1986 C5—Improved C4, with a lock-up converter
    • 1985–1994 A4LD—C3 with overdrive
    • 1989–1996 E4OD—C6 with overdrive
    • 1998–2004 4R100—Replaces the E4OD transmission
    • 1995–2001 4R44E—Electronically controlled A4LD, light-duty
    • 1995–1997 4R55E—Electronically controlled A4LD, heavy-duty
  • 1997–Current 5R44/5R55 Series—5-speed 5R44E/5R55E/N/S/W based on the 4R44E/4R55E, Bordeaux Automatic Transmission Plant / Sharonville Ohio transmission plant
    • Lincoln LS and Ford Thunderbird
    • 2005–2010 Ford Mustang V6, GT[1]
  • 1980–1993 AOD—Ford's first 4-speed automatic transmission, based on the FMX but with a torque-splitting feature.
    • 1992– AOD-E—Electronic AOD
      • 1993–2008 4R70W—Strengthened AOD-E with lower 1st and 2nd gear ratios
        • Application vary by year
      • 2003–2008 4R75E & 4R75W
        • Applications vary by year
          • 4.2L, 4.6L, & 5.4L (2v & 3v)
            • Ford E-Series Van
          • Ford Mustang (GT and Mach 1)
  • AXOD family—Van Dyke Transmission
    • 1986–1991 AXOD—4-speed transaxle
      • Ford Taurus, Lincoln Continental, Mercury Sable
    • 1991–1993 AXOD-E—4-speed electronic transaxle
      • Ford Taurus, Lincoln Continental, Mercury Sable
    • 1994–2003 AX4S—4-speed electronic transaxle
      • Ford Taurus, Ford Windstar, Lincoln Continental, Mercury Sable
    • 1995–2007 AX4N/4F50N—4-speed electronic transaxle
      • Ford Freestar, Ford Taurus, Ford Windstar, Lincoln Continental, Mercury Monterey, Mercury Sable
  • 1980–1994 FLC—3-speed hydraulic transaxle
    • Ford Escort, Ford Tempo, Mercury Topaz, Ford Taurus, Mercury Sable, and Ford EXP
  • 1989–1997 4EAT-G—4-speed Mazda design transaxle
  • 1990–2003 F-4EAT—4-speed electronic transaxle—Mazda transaxle
    • Ford Escort, Mercury Tracer
  • 2000-2013 4F27E--Strengthened 4-speed F-4EAT
    • Ford Focus, Ford Transit Connect
  • 1994–2007 CD4E—4-speed transaxle, Batavia Transmission—Replaces the 4EAT-G transaxle
    • Ford Contour, Ford Escape, Ford Mondeo, Ford Probe, Mercury Cougar, Mercury Mariner, Mercury Mystique, Mazda Tribute, Mazda 626.
  • 2003.5–2010 5R110W – 5-speed automatic with Tow/Haul mode – Replaces 4R100 in Super Duty trucks
  • 2011–2019 6R140 - 6-speed automatic with Tow/Haul mode - Replaces 5R110W in Super Duty trucks.[2]
  • 2020-present 10R140 - 10-speed automatic with Tow/Haul Mode - Replaces the 6R140 in Super Duty trucks.
  • 2005–present Aisin AWF-21 6-speed
    • Lincoln MKZ (2006-2010), Ford Fusion AWD (2007-2009), Land Rover LR2
  • 2005–2007 ZF-Batavia CFT30—Continuously variable transaxle (CVT)
    • Ford Freestyle, Ford Five Hundred, Mercury Montego
  • 2005–2016 6R60 ZF 6-speed transmission
    • Ford Falcon (BF, FG)
    • Ford Territory (AWD)
  • 2006-2009 Ford FNR5 transmission - A 5 speed automatic from Mazda, uses Ford FNR5 fluid
    • Ford Fusion, Mercury Milan
  • 2006–2007 6R60 6-speed transmission
    • Ford Explorer, Mercury Mountaineer
  • 2007–present 6R80 6-speed transmission
    • Ford Expedition, Lincoln Navigator, 2009 Ford F-Series, 2011 Ford Mustang (V6 & GT), 2011 Ford Territory, 2011 Ford Ranger (Note: Global excluding USA)
  • 2007–present 6F50—6-speed transaxle, Van Dyke Transmission
    • Ford Edge, Ford Explorer, Lincoln MKX, Lincoln MKS, Ford Taurus, Ford Flex, Lincoln MKT, Lincoln MKZ (2010-Present)
  • 2009–present 6F35—6-speed transaxle, Van Dyke Transmission
    • Ford Escape, Ford Fusion, Ford Focus, Ford C-Max, Ford Kuga (in the Focus, C-Max and Kuga it is used with the 1.5 L4 Ecoboost. Also used with the ford escape in 2.0 L4 GTDI variant, and rated for vehicles up to 3.0L)[3]
  • 2009–present 6F55—6-speed transaxle (designed for use with the 3.5L Ecoboost V6)
    • Lincoln MKS, Ford Flex, Ford Taurus SHO, Lincoln MKT, Ford Explorer Sport (2013-present)
  • 2013-present HF35 Hybrid and Plug in Hybrid transaxle.
    • Ford Fusion HEV, Ford Fusion Energi PHEV, Ford C-Max HEV, Ford C-Max Energi PHEV, Lincoln MKZ Hybrid.
  • 2017- 10R80 Ford-GM 10-speed automatic transmission[4][5]
    • 2017 Ford F-150 (including Ford Raptor), Ford Expedition, Ford Mustang
  • 2017–present 6F15—6-speed transaxle (designed for use with the 1.0 Ecoboost to replace the DPS6 Powershift transmission)
    • Ford EcoSport, Ford Focus, Ford C-Max
  • 2017-present 8F35 8-speed transverse transmission[6] (1.5 and 2.0 EcoBoost, 2.0 Duratorq)
    • Ford Edge, Ford Escape (2020),[7]Ford Focus, Ford S-MAX, Ford Taurus
  • 2017-present 8F40 8-speed transverse transmission (2.0 EcoBlue)
    • Ford Edge, Ford Focus, Ford S-MAX, Ford Galaxy, Ford Mondeo, Ford Kuga, Ford Mustang
  • 2018-present 8F24 8-speed transverse transmission (1.5 EcoBlue)
  • 2018-present 8F57 8-speed transverse transmission for higher torque (2.7 V6 EcoBoost)
    • Ford Edge ST, Ford Explorer, Ford Fusion, Ford Taurus

Dual-clutch automatics[edit]

Mt82 Transmission

These are dual-clutch transmissions.

  • 2008-present 6DCT150 Ford Powershift 6-speed wet clutch
  • 2008–present 6DCT250 Ford Powershift (DPS6) 6-speed dry clutch
    • Ford EcoSport, Ford Fiesta, Ford Focus.
    • The 2012-2016 DPS6 Powershift transmission was used in the 2012-2016 Ford Focus and 2011-2016 Ford Fiesta sedans. This transmission is the subject of a massive number of lawsuits alleging Ford lied in order to sell cars Ford knew had defective transmissions.[8]

Mt82 Transmission For Sale

  • 2008-present 6DCT450 Ford Powershift (MPS6) 6-speed wet clutch
    • Ford Focus, Ford Mondeo, Ford Kuga, Ford Galaxy, Ford Fiesta, Ford C-Max, Ford S-Max
  • Getrag Transmissions
    • 2017-present 7DCL750 Getrag - 7-speed
      • Ford GT (2nd gen. V6)
  • Tremec Transmissions
    • 2020-present Tremec TR-9070 7-speed

Manual[edit]

  • 1960-1967 Ford/Mercury HED 3-speed transmission (non-syncro first gear)
  • 1968- Ford Type E (aka Built or 2000e) 4-speed transmission Came in Anglia 105E, Cortina MkI, Lotus Cortina MkI, Cortina MkII to up to '68, Consul Classic, Consul Capri, Corsair, Escort TC, Mexico Mk1 and RS1600 MkI.
  • 1976–1985 BC or BC4
  • 1982–1995 BC5
  • 1995-present IB5
  • MT75
    • Ford Sierra, Ford Granada, Ford Escort Cosworth, Ford Scorpio, Ford Transit
  • 1981–1994 MTX-III
  • 1989–1995 MTX-IV
  • MTX-75, 'Cologne' transmission
    • Ford Contour, Ford Escort, Ford Focus, Ford Mondeo, Jaguar X-Type, Mercury Cougar
  • Type 9 (or Type N, T-9)
    • Ford Capri 1.6, 2.0 1983 onwards, Capri 2.8 1982 onwards, Ford Sierra 1.6, 1.8, 2.0, Sierra XR4i, Sierra XR4x4 2.8, Merkur XR4Ti
    • New Process 435 heavy duty 4 speed transmission
    • Clark / Tremec 4 speed OD and SROD
  • Tremec or Borg-Warner transmissions
    • Borg-Warner T-18/T-19 transmissions - circa 1966-1991 Ford F-Series
    • Borg-Warner T-10 transmission – 1957–1965[9]
    • Borg-Warner T-5 transmission – Ford Sierra; 1983–1995 Ford Mustang; 2005–2009 Mustang V6
    • Tremec T-170/T-175/T176/T177 1984-1990+? F-series
    • Tremec T-45 transmission – 1996–1999 Mustang Cobra, 1996–2000 Mustang GT
    • Tremec T-56 transmission – 2000 Cobra R and 2003–2004 Mustang Cobra, Ford Falcon (BF) I6T and 5.4l V8 BF MK1 - BF MK11
    • Tremec TR-3650 transmission – 2001–2010 Mustang GT
    • Tremec TR-6060 transmission – 2007–present Ford Shelby GT500, Ford Falcon (FG) I6T, 5.4L and 5.0L supercharged V8
  • Getrag transmissions
    • Getrag MT-285 6-Speed Manual - 2002-2004 Focus SVT
    • Getrag MT-82 - 2011-present Mustang GT
  • Mazda M5OD transmissions
    • M5OD-R1 – Ford Ranger, Bronco II, Explorer, Aerostar.
    • M5OD-R1HD – Ford Ranger (4.0L V6 only)
    • M5OD-R2 – Thunderbird Super Coupe, Ford F-150, Bronco (except with 351 cu in (5.8 L) V8)
  • Toyo Kogyo (Early Mazda)
    • TK 4 4 speed manual (No Overdrive) (Ranger, Bronco II 83-85, Aerostar 85)
    • TK 5 5 speed manual (With overdrive) (Ranger, Bronco II 85-87, Aerostar 85-87)

Mt82 Transmission Upgrades

Mitsubishi FM145/FM146 5 speed (overdrive) (Ranger/Bronco II 86-92 with 2.0L, 2.3L, and 2.9L engines only)

References[edit]

  1. ^Ford 5R55E transmission#5R44E/5R55E/N/S/W
  2. ^'Archived copy'. Archived from the original on 2011-09-12. Retrieved 2011-05-21.CS1 maint: archived copy as title (link)
  3. ^'6F35 Transmission parts, repair guidelines, problems, manuals'. go4trans.com. Retrieved 2020-11-02.
  4. ^'Exclusive: An Inside Look At Ford's New 10 Speed Transmission'. www.thetruthaboutcars.com. Retrieved 2015-03-16.
  5. ^'Saturation Dive: Ford 10 Speed Transmission Power Flow'. www.thetruthaboutcars.com. Retrieved 2015-04-17.
  6. ^Craig, Renneker. 'Sessions 2018'. CTI Symposium USA.
  7. ^oemdtc (2019-10-02). '8F35 – Illuminated MIL With DTC P0766 And/Or Intermittent No Reverse Engagement – 2019-2020 Ford & Lincoln Ford'. Retrieved 2020-11-02.
  8. ^Howard, Phoebe (May 9, 2018). 'Suit: Ford lied and blamed buyers' (Thursday, May 9, 2018). The Detroit Free Press. p. A1.
  9. ^10.asp Article from Classic Car Magazine[dead link]
