Nissan and its spinoff, Jatco, have produced a large number of automatic transmissions for many auto makers.

FORD LOOK-UP TABLE: Model. Transmission Type. Engine Type/Size. Transmission Model. 2000E: 1974: C4: 2000E: 1975-1981: C3: AEROSTAR: 1995: 4 SP RWD. All Nissan cars use the CVT, and Nissan provides a 10 year/100,000 mile warranty on the transmission. The Jatco CVT has been around for so long that I would not be terribly concerned about it. Missileman July 6, 2016, 5:19am #4 They take a little getting used to.

Naming

The first Nissan/Jatco transmission, the Jatco 3N71 transmission, used a simple naming scheme: the '3' meant '3-speed', and the remainder was the series number. Beginning in 1982, it gained a locking torque converter (L3N71b) for greater efficiency. (See L3N71 link below). It gained an overdrive section in 1983 (L4N71b), culminating with preliminary electronic sensors and control functions being added in 1985 (E4N71b), and proceeding with the initial 'R' for 'rear wheel drive' with the RL4R01A/RE4R01A. This same system was used with the RL3F01A front wheel drivetransaxle and its descendants through the RE4F04A.

Jatco Transmission

Jatco has switched to a new naming scheme starting with a 'J' for Jatco, then 'F' or 'R' for front- or rear-wheel drive. The next digit is the number of gears, while the model series is now two digits sequentially. The model series names were not directly mapped – for instance the model designation changed when the RE4F04A was renamed to JF403E, while the RE4R03A became the JR403E.

Many OEM users assign their own model numbers.

Conventional automatic transmissions

Longitudinal enginerear wheel drive transmissions

  • 1969–1989 3N71 (Nissan: L3N71B) — 3-speed
  • 1983–1990 4N71 (Jatco: JR401/JR401E, Nissan: L4N71B/E4N71B, Mazda: N4A-EL) — 4-speed
  • 1988–2004 4R01 (Jatco: JR402/JR402E, Nissan: RL4R01A/RE4R01A/RE4R01B, Mazda: R4A-EL) — 4-speed
  • ?–? 4R03 (Jatco: JR403E, Nissan: RE4R03A/RG4R01A) — 4-speed
  • ?–? JR405E (Mazda: RC4A-EL) — 4-speed
  • 1989–? 5R01 (Jatco: JR502E/JR503E, Nissan: RE5R01A) — 5-speed
  • 2002–present 5R05 (Jatco: JR507E/JR509E, Nissan: RE5R05A) — 5-speed
  • 2009–present 7R01 (Jatco: JR710E/JR711E, Nissan: RE7R01A/RE7R01B) — 7-speed[1]
  • 2019–present JR913E (JATCO JR913E 9 speed automatic transmission) — 9-speed[2][3][a]
Notes
a.^ Designed by Mercedes-Benz, modified and produced by Jatco under license for Nissan and Infiniti vehicles.
  • 1982–1990 RL3F01A/RN3F01A — 3-speed transaxle
  • 1982–1985 RL4F01A — 4-speed transaxle
  • 1985–1994 RE4F02A/RL4F02A — 4-speed transaxle
  • 1991–2001 RE4F03A/RL4F03A — 4-speed transaxle
  • 1992–2001 RE4F04A/RE4F04V — 4-speed transaxle (aka GEO/Isuzu 4F20E/JF403E and Mazda LJ4A-EL)
  • 3-speed ultra lightweight keicar
    • Suzuki Alto, Mazda Carol
  • 3-speed high-performance keicar
    • Mitsubishi eK Wagon, Mitsubishi Minica, Nissan Otti
  • 3-speed high-performance compact
    • Proton Perdana
  • 4-speed ultra lightweight keicar
    • Mitsubishi eK Active, Classy, Sport, Wagon, i, Nissan Otti
  • Jatco JF405E — 4-speed ultra-light compact (formerly JF402E)
    • Suzuki Wagon-R, Suzuki MR Wagon, Nissan Moco, Mazda AZ-Wagon, Mazda Laputa, Hyundai Atoz, Kia Morning, Daewoo Matiz
  • Jatco JF404E — 4-speed ultra-light compact
    • VW Polo, VW Lupo, SEAT Arosa, Škoda Fabia
  • 4-speed compact
    • Nissan Tiida, Nissan Note, Nissan March, Nissan Wingroad, Nissan Bluebird Sylphy, Renault Samsung SM3
  • 4-speed small/medium
    • Mitsubishi Grandis, Mitsubishi Galant, Mitsubishi Lancer, Mitsubishi Lancer Wagon
  • 4-speed medium
    • Mitsubishi Lancer Cargo

Cars With Jatco Transmissions

Jatco JF613E 6-speed automatic transmission as used in the Renault Laguna.
  • 4-speed medium/large
    • Nissan Altima, Nissan Quest, Nissan X-Trail, Renault Samsung SM5
  • Jatco JF506E/F5A5 5-speed medium/large
    • VW Golf, VW Sharan, MG Rover, Land Rover Freelander, Jaguar X-Type, Ford Mondeo, Audi A3, Mazda MPV, Mitsubishi Lancer Evolution
  • Jatco JF613E 6-speed medium/large
    • Renault Laguna, Renault Scénic, Nissan Qashqai, Mitsubishi Outlander

Continuously variable transmissions

Jatco Transmission Identification

Jatco JF011E and Nissan MR20DE engine.

Front wheel drive

  • Jatco JF011E
    • Nissan Lafesta, Nissan Serena, Nissan Sentra, Renault Fluence, Nissan Bluebird Sylphy, Nissan X-Trail (T31), Mitsubishi Outlander (2008-), Mitsubishi Lancer (2008-), Mitsubishi Outlander Sport (2011-), Dodge Caliber, Jeep Compass, Jeep Patriot, Suzuki Kizashi
  • Jatco JF009E
    • Nissan Tiida (Versa), Nissan Note, Nissan Cube, Nissan March, Nissan Wingroad
  • Jatco F1C1
    • Mitsubishi Colt, Mitsubishi Colt Plus, Mitsubishi Lancer (non US market, pre-2008)
  • Jatco F06A
  • Jatco JF010E
    • Nissan Teana, Nissan Presage, Nissan Murano
  • Jatco CVT7 (Jatco JF015E / Wide ratio Jatco JF020E) Ratio coverage 7.3 and 8.7 for WR
    • Mitsubishi Mirage, Mitsubishi Delica D:2, Nissan Cube, Nissan Juke, Nissan Latio, Nissan March, Nissan Note, Nissan Sylphy, Nissan Lannia, Suzuki Alto Eco, Suzuki Hustler, Suzuki Solio, Suzuki Spacia, Suzuki Splash, Suzuki Swift, Suzuki Wagon R
  • Jatco CVT8 (Jatco JF016E / Jatco JF017E / Hybrid Jatco JF018E / Hybrid Jatco JF019E) Ratio coverage 7.0
    • Infiniti QX60, Nissan NV200, Nissan Serena, Nissan Teana, Nissan X-Trail, Nissan Rogue (USA & Canada)
  • Jatco CVT S Ratio coverage 6.0

Rear wheel drive

  • Jatco JR006E: Toroidal CVT
    • Nissan Skyline 350GT-8 (2002-2006)
Jatco

Hybrid vehicle systems

  • JR712E Rear wheel drive; 7-speed Hybrid vehicle.[4] 3.5L V6 Engine Infiniti Q50
  • CVT 8 for Serena S Hybrid (Mild hybrid) 2013
  • CVT 8 Hybrid for Nissan Pathfinder Hybrid 2014 and Infiniti QX60 Hybrid 2014-2018
  • CVT 8 Hybrid for Nissan X-Trail 2015

www.wikipedian.netJatco 7R01 transmission

Conventional Automatic Transmissions

  • Longitudinal engine rear wheel drive
    • 1969–1989 L3N71B — First Jatco-developed 3-speed
    • 1983–1987 L4N71B/E4N71B — 4-speed light/medium duty (aka Mazda N4A-EL)
    • 1988–2001 RL4R01A/RE4R01A — 4-speed light/medium duty (aka Mazda R4A-EL)
    • RE4R03A/JR403E/RG4R01A — 4-speed
    • 1989–? RE5R01A — 5-speed
      • Nissan Skyline, Nissan Cedric, Nissan Gloria, Nissan Laurel, Nissan Cefiro
    • 2002–? RE5R05A — 5-speed
  • Transverse engine front wheel drive
    • 1982–1990 RL3F01A/RN3F01A — 3-speed transaxle
    • 1982–1985 RL4F01A — 4-speed transaxle
    • 1985–1994 RE4F02A/RL4F02A — 4-speed transaxle
    • 1991–2001 RE4F03A/RL4F03A — 4-speed transaxle
    • 1992–2001 RE4F04A/RE4F04V — 4-speed transaxle (aka GEO/Isuzu 4F20E/JF403E and Mazda LJ4A-EL)
  • Front wheel drive transaxles
    • 3-speed ultra lightweight keicar
      • Suzuki Alto, Mazda Carol
    • 3-speed high-performance keicar
      • Mitsubishi eK Wagon, Mitsubishi Minica, Nissan Otti
    • 3-speed high-performance compact
      • Proton Perdana
    • 4-speed ultra lightweight keicar
      • Mitsubishi eK Active, Classy, Sport, Wagon, i, Nissan Otti
    • Jatco JF405E — 4-speed ultra-light compact (formerly JF402E)
      • Suzuki Wagon-R, Suzuki MR Wagon, Nissan Moco, Mazda AZ-Wagon, Mazda Laputa, Hyundai Atoz, Kia Morning, Daewoo Matiz
    • Jatco JF404E — 4-speed ultra-light compact
      • VW Polo, VW Lupo, SEAT Arosa, Škoda Fabia
    • 4-speed compact
      • Nissan Tiida, Nissan Note, Nissan March, Nissan Wingroad, Nissan Bluebird Sylphy, Renault Samsung SM3
    • 4-speed small/medium
      • Mitsubishi Grandis, Mitsubishi Galant, Mitsubishi Lancer, Mitsubishi Lancer Wagon
    • 4-speed medium
      • Mitsubishi Lancer Cargo
TransmissionJatco Transmission
    • 4-speed medium/large
      • Nissan Altima, Nissan Quest, Nissan X-Trail, Renault Samsung SM5
    • Jatco JF506E 5-speed medium/large
      • VW Golf, VW Sharan, MG Rover, Land Rover Freelander, Jaguar X-Type, Ford Mondeo, Mazda MPV
    • 5-speed medium/large
      • Mitsubishi Eclipse Spyder, Mitsubishi Lancer Evolution Wagon
    • Jatco JF613E 6-speed medium/large
      • Renault Laguna, Renault Scénic, Nissan Qashqai, Mitsubishi Outlander
  • Rear wheel drive transmissions
    • 4-speed keicar
      • Mitsubishi Town Box, Mitsubishi Pajero Mini, Mitsubishi Minicab, Nissan Clipper Van and Truck
    • 4-speed medium
      • Nissan Skyline, Nissan Stagea
    • Jatco JR405E transmission — 4-speed
    • 4-speed medium
      • Mazda RX-8, Mazda Bongo
    • 4-speed medium/large
      • Nissan Cima 4WD
    • 5-speed medium/large
      • Mitsubishi Pajero
    • Jatco JR507E — 5-speed medium/large
      • Nissan President, Nissan Cima, Nissan Fuga, Nissan Skyline, Nissan Elgrand, Nissan Fairlady Z, Subaru Legacy Turbo
    • Jatco JR710E/JR711E: 7-speed medium/large
      • Infiniti G37, Infiniti EX37, Infiniti FX50
    • Jatco JR712E: 7-speed medium/large Hybrid
      • Infiniti M35h, Nissan Fuga Hybrid
