8hp70 Gear Ratios
Although the 8HP features 2 more speeds than the extremely successful 6HP, the dimensions have remained unchanged and the weight was even reduced by 3% to 87 kg (transmission modular system 8HP70) including oil. At the same time, the total transmission ratio spread of 7.0 ensures that the engine is always in its optimum operating range. CHRY 10' HP Series 8HP70 Torque Converter $1,399.00 HP Series Multi Disk Torque Converter Torque Converter Diameter - 10' Available in stall speeds from 2800-3400 rpm Buy in monthly payments with Affirm on orders over $50. Bolt on Yoke for an 8 speed Automatic found in most of the 2014 and latter Challengers, Chargers, 300's, & some trucks. Exact application for fitment is 8HP70 and 8HP90. With this yoke, it makes building a custom driveshaft easy for most Driveshaft Shops. 8HP70 are found in the 5.7L & 6.4L Vehicles. 8HP-90 found in the 6.2L Hell cat, Red Eye.
For the 8-speed automatic transmission, ZF set out to design and develop an entirely new gear set concept. The result is a revolution in transmission design: a transmission concept with 4 gearsets which requires only 5 shift elements – of which only two are open in any given gear. The 8HP also requires no more than 3 multi-disk clutches and 2 brakes, which allows it to achieve a greater degree of efficiency than other concepts. As a result of the fact that only 2 shift elements are open per gear, drag losses in the transmission are sustainably reduced. This effect is supported by the use of a new parallel-axis vane-type oil pump. 4 A torque range from 300 to 1000 newton meter makes the 8HP the perfect partner for all rear-wheel-drive and all-wheel-drive designs. From the lower midsize segment to sporty luxury cars, and in every type of SUV and offroad vehicle – its revolutionary design is always an efficient and economical solution. Although the 8HP features 2 more speeds than the extremely successful 6HP, the dimensions have remained unchanged and the weight was even reduced by 3% to 87 kg (transmission modular system 8HP70) including oil. At the same time, the total transmission ratio spread of 7.0 ensures that the engine is always in its optimum operating range. This translates into improved acceleration and reduced fuel consumption.
Based on a really successful product, it combines dynamics and comfort with improved efficiency – also with regard to the costs. And it is ideally equipped for even stricter fuel consumption and CO2 emission regulations. In the premium and mid-size car range, the optimized 8HP product family enables the average fuel consumption to be cut by another 3%. CO2 emissions decrease to the same extent. These potentials can also be completely transferred to hybrid drives. Incidentally, additional savings potential by a further optimized startstop function is not yet included here. To achieve these innovations, ZF engineers have optimized some details. Thus, the reduction of drag torques and engine speeds further reduced the already very low power losses. Essential success aspects are the higher transmission ratio spread and the reduction of system pressures in many areas. Another factor is the multidisk separation of the brakes. Furthermore, advanced torsional vibration dampers enable a faster bypassing of the hydrodynamic power transmission and therefore further reduction in speed. Thus, the new 8HP is perfectly prepared for use with the new engines (3-8 cylinders) which will determine the trend of the years-to-come.
I just finished swapping a 8 speed auto from a dodge ram into my 67 chevelle.
I'm posting this only to offer anyone interested in doing this any help / advice based on what I did to make it work.
it's really not too bad, I decided to rip the existing controller out of the tranny and used an external one.
other than that I used an ati adapter plate and 153 tooth gm flex plate to mate it up.
I am currently manually shifting using two buttons, shift up and shift down. I'll be adding auto mode someday however manual mode is really what I was after,
I actually only lock up the converter after 8th so it feels like a 9 speed.
it's basically the same as the hellcat tranny, I shift in under 200 ms and it barks the tires in every gear.
there's probably better trannys to use but I've tried 2sp, 3sp,4sp od, and a t56. This 8 spd kills them all
Again, I'm only posting to help others interested in doing this, it took me a lot of searching to find the info so I'd be happy to help anyone save some time do this.
