62te

Posted on  by admin
62te

JASPER® remanufactured Chrysler 62TE transmissions are built to meet, or exceed, OEM measured standards and have a 3 year/100,000 mile nationwide, transferable parts and labor warranty. Click here for complete warranty information. This automatic transmission is completely remanufactured, assembled to exacting tolerances, and live-run dynamometer tested for reliability.

The 62TE transmission family is widely used in popular applications such as the Chrysler 200, Pacifica, Sebring, Town & Country; Dodge Avenger, Grand Caravan, Journey; Ram C/V, Promaster; and Volkswagen Routan.

The 62TE transmission family is prone to issues that include: loss of 3rd or 6th gear, pump cross leaks, cooler system contamination/failure, high bearing failure rate, cracked/leaking front cover bolt holes, burning of torque converter lining and TCC slip codes, solenoid failure/line pressure codes,

62te transmission

The 62TE is a six-speed derivative of the 41TE first introduced on 2007 Chrysler Sebring models fitted with the 3.5 L EGJ V6. Applications also include the Pacifica crossover (4.0 L), the RT Platform minivans (3.8 L & 4.0 L V6; also 2.8 L Diesel for Europe), and the Dodge Journey (3.5 L) Check out our 3,564 reviews. The 62TE six-speed automatic transaxle was based on Chrysler's existing four-speed automatic, with two new primary gear ratios and a secondary ratio for passing at highway speeds. The first gear ratio was much lower, to increase standing-start acceleration; and the differential was beefed up to handle more power. Originally designed for Avenger, Sebring and Pacifica models, the 62TE was later adopted into various Dodge vehicles. The 62TE took major strides ahead of its predecessor the 41TE with the addition of two more gears and the ability to handle more torque.

62te

cracked lock-up piston, lock-up failure, and vibration/noise.

62te


JASPER remanufacturing advantages include:

62te

  • JASPER prevents loss of the 3rd and 6th gear by installing an improved snap ring in the case. JASPER’s snap ring is 27% greater in radial thickness which significantly increases the retaining force, ensuring the snap ring remains engaged.

  • JASPER prevents hydraulic leaks between the Underdrive, Overdrive, and Reverse clutch by installing solid PTFE stator support seals. PTFE seals are superior to OE metal seals in separating these hydraulic circuits.

  • 100% installation of a NEW cooler bypass valve.

  • 100% NEW transfer gear bearings

  • JASPER 100% installs a billet converter cover to prevent cracks.

  • 100% NEW converter linings installed.

  • JASPER remanufactures the solenoid pack and replaces all seals with NEW seals. It is then tested on a state-of-the-art test machine prior to installation to assure proper operation.

  • JASPER installs a NEW heavy duty billet lock-up piston for the 2011-2017 3.6L FWD & AWD, and 2014-2018 3.6L Promaster.

  • 100% NEW TCC lock-up solenoid

Each converter is dynamically balanced. The external converter shell is balanced independently of the converter stator and turbine to ensure the converter is accurately balanced.

62te Compounder Assembly

Please visit our Video Library to learn more about some of the quality processes we perform to this transmission family.

62te

62te Diagram

Go to our online catalog to get a price on a JASPER Chrysler 62TE automatic transmission for your specific vehicle application. Most applications of the JASPER remanufactured 62TE transmission are available immediately from our huge distribution network throughout the U.S. This means you can be up and running again quickly and reliably. So, as soon as you get a price from our online catalog, just click on the “Find an Installer” icon to find the installer closest to you.

The 62TE six-speed automatic was launched in 2007 with the V6 on the Sebring and Avenger, and with the Pacifica. It then rolled into minivans including the Dodge Grand Caravan and Chrysler Town and Country. With some case modifications from 2010 to 2011 updates were completed to help with the durability of the 62TE platform. This transmission is now used in the Ram Premasters cargo vans. Chrysler 62TE Transmission JASPER® remanufactured Chrysler 62TE transmissions are built to meet, or exceed, OEM measured standards and have a 3 year/100,000 mile nationwide, transferable parts and labor warranty. Click here for complete warranty information.

62te Transmission Rebuild Kit

Full warranty disclosure available on our website or upon request. Specifications subject to change without notice.
