The 5R110 TorqShift transmission is one of the most robust transmissions ever offered in a medium duty pickup. It does however have a weakness. The 5R110 transmission is controlled through the use of solenoids to turn on and off gears. A gear is commanded by the computer and a solenoid applies fluid. 5R110W Performance and Heavy Duty Transmissions and Parts from PATC. This is our strongest 5R110W transmission. The level four 5R110W comes with a Transgo Reprogramming Kit for better shifts. Extra Alto Red Eagle clutches and Kolene steels are added to the forward and direct clutch sets for more holding power. Home SHOP Transmissions Ford Transmissions 5R110 Transmission The 5R110 was built for heavy duty Ford vehicles and was launched in 2003. While advertised as a 5 speed, the 5R110 actually does come with a hidden sixth gear that only activates during extreme cold weather. Jul 24, 2018 Sonnax Transmission parts for Ford 5R110W applications. Sonnax is an industry leader in the cutting edge design, manufacture and distribution of the highest quality products to the automotive aftermarket, commercial vehicle industries, and industrial sectors utilizing drivetrain technology.

Ford 5R110W TorqShift 5 speed automatic transmission specs, ratios, and troubleshooting information. The 5R110W was introduced alongside the 6.0L Power Stroke during the 2003 model year. Ford continued to offer the transmission behind the later 6.4L Power Stroke, but ultimately retired the gearbox in favor of an upgraded 6 speed unit for the 2011 model year.

Truck drivers LOVE their trucks. And rightfully so. However, heavy-duty trucks that use the Ford 5R110W TorqShift 5-speed automatic transmission have experienced some pretty frustrating challenges. Let’s look at some of the most common 5R110W transmission problems.

5r110w Transmission5r110w Transmission

The Ford 5R110W TorqShift 5-speed automatic transmission was designed after the 4R100 4-speed automatic transmission. The 5R110W was designed to foster better performance, fuel mileage, and enhanced control of shift quality and shift strategy. Additionally, the 5R110W allowed for more control of gear selection with a switch or paddle shifter. The shifts were smoother because they were controlled by seven linear solenoids, which were controlled by computer.

Pressure control solenoids that use 0 to 1 amps, variable by the transmission control module computer, controls 5 gears, shift points, shift quality, and reverse drive engagements. There is also a limp mode feature to let the driver know that it’s important to take the vehicle to a transmission shop. Code setting errors help with guided repairs.

5r110w Transmission Parts

For the 5R110W, the cold weather shift strategy normal is 1st-2nd-3rd-5th-6th. The secondary shift sequence, when ambient temperature is below 5° F, is 1st-2nd-3rd-4th-6th. The transmission’s 4th gear is used in cold weather to increase engine RPM to help the engine and the transmission reach normal operating temperature in less time.

5r110w Performance Transmission

Modified direct clutch solenoid after-market

5r110w Transmission

Problems arise when using a modified direct clutch solenoid to raise pressure to the direct clutch.

These problems include:

  1. The shift strategy is not programmed the same for all trucks so the results will not be the same for all model trucks, which includes modified engines, after-market tunes, tire size, gear ratio, internal modifications to the transmission, shifting problems, and failure.
  2. Harsh 3rd to 5th shift.
  3. Flared shift 3rd to fifth.
  4. Rough coast downshift 5th to 3rd.
  5. Shifting becomes erratic because the computer strategy is making continuous big changes.
  6. Direct clutch failure due to the bottom clutch plate bending, which is caused by pressure being too high, so the clamping force is reduced to the direct clutch after the plate bends, causing failure of the direct clutch.

5R110W Adaptive Strategy

The 5R110W Torqshift transmission has an adaptive shift schedule computer-controlled adaptive strategy. This system learns driving habits and creates a shift schedule by adjusting AMPS to the 7 solenoids raising and lowering pressure produced by driving behavior. The adaptive strategy then creates a shift schedule for individual drivers. Through a continuous process, the system measures the time it takes for a shift to occur. From the time the transmission control module commands the shift to the time the shift is complete, the TCM compares this value to the programmed time and makes pressure adjustments by adjusting AMPS to shift the solenoids. Optimization of engagement pressures is the primary objective of the adaptive strategy.

This is where the problem starts. First, there are modified shift solenoids and clutch plates with different types of friction material. Additionally, the programming may have been changed by an after-market programmer. Also the boosting engine power and tire size might have changed, all creating an atmosphere for issues.

Our Solution

5r110w Transmission Pan

At Thurston County Transmission, we rebuild your Ford 5R110W transmission so that it will last well beyond the flawed model. With our expertise in vehicle transmissions, your car will work better than new, and the rattling, bumping, and knocking you experience will be a thing of the past. If you suspect that you have transmission issues with your automobile,contact us today!
